Description
Overview
The RG-ANT20S-90 is a high-gain sector panel antenna intended for outdoor, long-range 5 GHz wireless links and network extensions. It pairs with Reyee RG-AirMetro550G-B radios and is suited for service providers and small businesses that need directed coverage with on-site installation and ongoing support for alignment, cabling, and configuration.
Key Features
- Designed for Reyee RG-AirMetro550G-B compatibility
- 20 dBi gain for improved link budget and extended range
- Operates in the 5 GHz band
- 90° horizontal beamwidth for sector coverage
- 7° vertical beamwidth for focused elevation control
- 2 x SMA antenna connectors for external radio interfaces
- Estimated link capability up to 10 km (line-of-sight conditions)
- IP55-rated enclosure for protection against dust and water spray
Compatibility / Requirements
- Requires a radio or access point with external antenna ports and SMA-compatible connectors (explicitly listed for RG-AirMetro550G-B)
- Clear line-of-sight is recommended to achieve long-range links (up to 10 km)
- Suitable mounting structure and alignment tools are required for optimal performance
- Cabling, connectors, and grounding provisions are needed at the installation site
- What’s in the box: not specified
What’s Included
- Product details only: Reyee AirMetro 90° sector antenna (model RG-ANT20S-90) — additional accessories and packaging contents not specified
Support Options
We offer professional installation and ongoing support options to deploy this antenna reliably in production environments. Services can include on-site mounting and alignment, cabling and grounding, radio configuration and tuning, performance testing, and ongoing managed support or scheduled maintenance.
